The collision from qwertyquerty

Info

Collision is a python library that is meant for collision detection between convex and concave polygons, circles, and points.

Installation

To get the latest stable version:

pip install collision

To get the latest development version run:

pip install https://github.com/qwertyquerty/collision/archive/master.zip

Classes

class `collision.Vector(x, y)`

A 2D vector/point class

Properties:

x (int) or (float) - The x-coordinate
y (int) or (float) - The y-coordinate

Methods:

func `copy()` → `collision.vec`

Return a copy of the vector

func `set(v)`

Copy another vector's values onto the target vector

v (collision.vec) - The vector to copy from

func `perp()` → `collision.vec`

Return the vector rotated perpendicularly

func `rotate(angle)` → `collision.vec`

Return the vector rotated to the angle

angle (int) or (float) - Radians to rotate the point

func `reverse()` → `collision.vec`

Return a reversed version of the vector

func `normalize()` → `collision.vec`

Return a normalized version of the vector

func `project(v)` → `collision.vec`

Return the vector projected onto the passed vector

v (collision.vec) - The vector to project upon

func `project_n(v)` → `collision.vec`

Return the vector projected onto a unit vector

v (collision.vec) - The vector to project upon

func `reflect(axis)` → `collision.vec`

Return the vector reflected upon the passed axis vector

axis (collision.vec) - The axis to reflect upon

func `reflect_n(axis)` → `collision.vec`

Return the vector reflected upon the passed axis unit vector

axis (collision.vec) - The axis to reflect upon

func `dot(v)` → `int or float`

Returns the dot product of the vector and another

v (collision.vec) - The other vector for the dot product

func `ln()` → `int or float`

Returns the length of the vector

func `ln2()` → `int or float`

Returns the squared length of the vector

class `collision.Circle(pos, radius)`

A simple circle with a position and radius

Properties:

pos (collision.vec) - The center coordinate of the circle
radius (int) or (float) - The radius of the circle
aabb (tuple(tuple(int or float)) - The axis alligned bounding box of the circle

class `collision.Poly(pos, points, angle = 0)`

A convex polygon with a position, a list of points relative to that position, and an angle

Properties:

pos (collision.vec) - The center coordinate of the circle
points (list[collision.vec]) - A list of absolute points (each relative point + the position of the polygon.) Can not be directly edited.
rel_points (list[collision.vec]) - A list of points relative to the position. This property should not be directly changed.
angle (int) or (float) - The angle which the polygon is rotated. Changing this will cause the polygon to be recalculated.
aabb (tuple(tuple(int or float)) - The axis-aligned bounding box of the Poly

Class Methods:

func `Poly.from_box(pos, width, height)` → `collision.Poly`

Creates a polygon from

pos (collision.vec) - The center coordinate of the polygon/box
width (int) or (float) - The width of the box
height (int) or (float) - The height of the box

Methods:

func `set_points(points)`

Change the base points relative to the position. After this is done, the polygon will be recalculated again. The angle will be preserved. Use this instead of editing the points property.

func `get_centroid()` → `collision.vec`

Get the centroid of the polygon. Arithmetic means all of the points.

class `collision.Concave_Poly(pos, points, angle = 0)`

A concave polygon with a position, a list of points relative to that position, and an angle. This takes longer to collide than a regular Poly does, so only use this, if your shape must be concave.

Properties:

pos (collision.vec) - The center coordinate of the circle
points (list[collision.vec]) - A list of absolute points (each relative point + the position of the polygon.) Can not be directly edited.
rel_points (list[collision.vec]) - A list of points relative to the position. This property should not be directly changed.
tris (list[collision.Poly]) - A list of triangles relative to the position on the poly that makes up the concave polygon is used for concave collisions.
angle (int) or (float) - The angle which the polygon is rotated. Changing this will cause the polygon to be recalculated.
aabb (tuple(tuple(int or float)) - The axis alligned bounding box of the Poly

Methods:

func `set_points(points)`

Change the base points relative to the position. After this is done, the polygon will be recalculated again. The angle will be preserved. Use this instead of editing the points property.

func `get_centroid()` → `collision.vec`

Get the centroid of the polygon. Arithmetic means all of the points.

class `collision.Response()`

The result of a collision between two objects. It may optionally be passed to collision tests to retrieve additional information. At its cleared state, it may seem to have odd values. Ignore these, they are just there to make generating the response more efficient. The response should be ignored unless there is a successful collision.

Properties:

a (collision shape) - The first object in the collision test
b (collision shape) - The second object in the collision test
overlap (int) or (float) - Magnitude of the overlap on the shortest colliding axis
overlap_n (collision.vec) - The shortest colliding axis (unit vector)
overlap_v (collision.vec) - The overlap vector. If this is subtracted from the position of a, a and b will no longer be colliding.
a_in_b (bool) - Whether a is fully inside of b
b_in_a (bool) - Whether b is fully inside of a

Methods:

func `reset()` → `collision.Response`

Reset the Response for re-use, and returns itself

Collisions

func `collision.collide(a, b, response = None)` → `bool`

Test two shapes against each other. If a response is passed, and there is a collision, that response will be updated to the response values. The response will not be generated if there is no collision and it will be at its default values. Concave polys currently do not support responses.

a (collision shape) - The first shape to test
b (collision shape) - The second shape to test
response (collision.Response) - Optional response that will be updated if there's a collision.

func `collision.test_aabb(a, b)` → `bool`

Test two axis-aligned bounding boxes against each other. This is already done in collision.collide so there's no need for you to do it for optimization.

a (tuple(tuple(int or float))) The first AABB
b (tuple(tuple(int or float))) The second AABB

Algorithm issue

I believe, there is an issue in the collision recognition. Example:

`import pygame as pg
import sys
import os
from collision import *

SCREENSIZE = (1200,900)
screen = pg.display.set_mode(SCREENSIZE, pg.DOUBLEBUF|pg.HWACCEL)

v = Vector
p0 = Concave_Poly(v(0,0), [])
p0.set_points([
Vector(697.1654965313376, 179.9115879140274),
Vector(764.9587442373818, 222.3859986276198),
Vector(743.3817435948768, 256.82496846229026),
Vector(675.5884958888325, 214.35055774869784),
])
p1 = Concave_Poly(v(0,0), [])
p1.set_points([
Vector(875.0138897016246, 123.17802988652383),
Vector(943.1811884599225, 165.04949248334466),
Vector(949.304599935167, 170.46229454571227),
Vector(1019.8568670514846, 271.73421253085047),
Vector(1040.1360798659869, 381.7005038144338),
Vector(1020.1348828367004, 479.85313011280556),
Vector(974.5176923937827, 555.6645122896266),
Vector(939.825961238999, 534.4962957968701),
Vector(980.5408637494689, 470.69216659798064),
Vector(999.8705586307079, 387.20481118696586),
Vector(985.0376168510401, 292.6920133572453),
Vector(927.0230429423466, 204.44967187871185),
Vector(921.9104854607375, 199.67848025255998),
Vector(853.7431867024396, 157.80701765573914),
])

clock = pg.time.Clock()
stop = False
cont = False
while 1:
for event in pg.event.get():
if event.type == pg.QUIT:
sys.exit()
pressed = pg.key.get_pressed()

    # Hit SPACE to continue after the error
    if pressed[pg.K_SPACE]: cont = True

screen.fill((0,0,0))

if not stop or cont: p0.pos.x += 0.1

p0c, p1c, p2c = (0,255,255),(0,255,255),(0,255,255)
p0bc = (255,255,255)
p1bc = (255,255,255)

if collide(p0,p1):
    p1c = (255,0,0); p0c = (255,0,0);
    stop = True

if test_aabb(p0.aabb,p1.aabb): p1bc = (255,0,0); p0bc = (255,0,0);

pg.draw.polygon(screen, p0c, p0.points, 3)
pg.draw.polygon(screen, p1c, p1.points, 3)
pg.draw.polygon(screen, p0bc, (p0.aabb[0],p0.aabb[1],p0.aabb[3],p0.aabb[2]), 3)
pg.draw.polygon(screen, p1bc, (p1.aabb[0],p1.aabb[1],p1.aabb[3],p1.aabb[2]), 3)

pg.display.flip()
clock.tick(100)
