ACTORS - Fast ECS (Entity Component System) Framework for Unity

ACTORS is a complete game framework with multiscene editing, game object pooling, ECS and data-driven approach for game logic explicitly built for Unity. It is used to ease the pain of decoupling data from behaviors without tons of boilerplate code and unnecessary overhead.

Requirements

Unity 2018 and higher

How to Install

From packages ( Preferable )

Create a new Unity Project
Open the manifest.json file in the Packages folder inside of the Project
Add "com.pixeye.ecs": "https://github.com/dimmpixeye/actors.git",

From Unity

Download from https://github.com/dimmpixeye/ecs/releases

How To Update

If you use packages you can automatically get fresh updates inside Unity editor!
Press Tools->Actors->Update Framework[GIT] to get new update when needed.

Documentation

Examples ( In progress )
Wiki ( In progress )

Basic

Components

Components are data containers without logic. In ACTORS Framework components can be either classes or structs. You should decide carefully from the start of the project what kind of layout ( class or structure ) you want to use as the workflow slightly differs.

You can automatically create a component class/struct from a special template in Unity.
Project->Create->Actors->Generate->Component

Class Components

	sealed class ComponentHealth
	{
		public int val;
		public int valMax;
	}

Struct Components

To use struct components you need to add ACTORS_COMPONENTS_STRUCTS to Scripting Define Symbols in the Project Player Settings.

	struct ComponentHealth
	{
		public int val;
		public int valMax;
	}

Component Helper

Every component is generated with special helpers that are optional but makes your life way easier.
If you don't use Unity for generating components, you can easily make a template in your IDE. Or type helpers manually.

	static partial class component
	{
	       // auxiliary excluding filter for entity groups
		public const string Health = "ComponentHealth";
               // a shortcut to get compontent like this : entity.ComponentHealth();
		public static ref ComponentHealth ComponentHealth(in this ent entity)
			=> ref Storage<ComponentHealth>.components[entity.id];
	}

	sealed class StorageComponentHealth : Storage<ComponentHealth>
	{
	        // This is for performance. Adding new Component is much faster than new T();
		public override ComponentHealth Create() => new ComponentHealth();

                // Every time one or more components are removed from the entity the dispose method will run.
                // Use this method for cleanup and reverting settings of the component.
		public override void Dispose(indexes disposed)
		{
			foreach (var id in disposed)
			{
				ref var component = ref components[id];
                                component.val = 0;
			}
		}
	}

Entity

Entity is an incremental ID that help accessing components. Entity is represented by ent structure.

How to create entity ?

public void SomeMethod()
{
    // Bare entity
    ent e = Entity.Create();
}

Entities can hold information about unity objects as well!

public void SomeMethod()
{
     // New entity with a new GO ( GameObject ).
     // The GO prefab will be taken from the Resources folder by string ID.
     ent e = Entity.Create("Obj Fluffy Unicorn");
     // Access to the transform of Obj Fluffy Unicorn gameobject.
     e.transform.position = new Vector3(0,0,0) ;
}

public GameObject prefabFluffyUnicorn;
public void SomeMethod()
{
     // New entity with a new GO ( GameObject ).
     // The GO will be created from the provided prefab.
     // The GO will be pooled.
     ent e = Entity.Create(prefabFluffyUnicorn, true);
     // Access to the transform of Obj Fluffy Unicorn gameobject.
     e.transform.position = new Vector3(0,0,0) ;
}

You can pool gameobject by adding true variable in the end of the method.

public void SomeMethod()
{
     // New entity with a new GO ( GameObject ).
     // The GO prefab will be taken from the Resources folder by string ID.
     // The GO will be pooled.
     ent e = Entity.Create("Obj Fluffy Unicorn", true);
     // Access to the transform of Obj Fluffy Unicorn gameobject.
     e.transform.position = new Vector3(0,0,0) ;
}

How to add Components ?

There are several ways to add components depending on the context of your code. In case you want to setup your new entity use Set Method. Use Set method only with newly created entities.

public void SomeMethod()
{
     ent e = Entity.Create("Obj Bunny");
     // Add components
     var cCute       = e.Set<ComponentCute>();
     var cJumping    = e.Set<ComponentJumping>();
     var cConsumable = e.Set<ComponentConsumable>();
     var cPoo        = e.Set<ComponentCanPoo>();

     // Component Cute
     cCute.attractivness = float.PositiveInfinity;
     // Component Jumping
     cJumping.power = 100;
}

Use Add method when you want to attach new component to already existed entity.

public void SomeMethod()
{
     // where e is some entity.
     // Add components
     var cCute       = e.Add<ComponentCute>();
     var cJumping    = e.Add<ComponentJumping>();
     var cConsumable = e.Add<ComponentConsumable>();
     var cPoo        = e.Add<ComponentCanPoo>();

     // Component Cute
     cCute.attractivness = float.PositiveInfinity;
     // Component Jumping
     cJumping.power = 100;

}

The difference between Add and Set are in the operations that Framework must do to create this object. In the example above, the Framework needs to make 4 ADD operations, but in the case of the SET method, it will make only 1 operation.

Use AddGet method when you unsure if entity has particular component. This method will check and add component if it doesn't exist.

public void SomeMethod()
{
     // where e is some entity.
     // Add components
     var cCute       = e.AddGet<ComponentCute>();
     var cJumping    = e.AddGet<ComponentJumping>();
     var cConsumable = e.AddGet<ComponentConsumable>();
     var cPoo        = e.AddGet<ComponentCanPoo>();

     // Component Cute
     cCute.attractivness = float.PositiveInfinity;
     // Component Jumping
     cJumping.power = 100;

}

How to kill Entities?

// Create new entity with Obj Bunny prefab
ent e = Entity.Create("Obj Bunny");
// Somewhere in the code
e.Release();

If you create an entity with a GameObject, it will be destroyed as well. If the GameObject was marked as poolable, it will be deactivated and reused in the future.

How to kill Entity without touching a GameObject?

// Create new entity with Obj Bunny prefab
ent e = Entity.Create("Obj Bunny");
// Somewhere in the code
e.Unbind();

Processors

Processors are systems in ACTORS framework. You execute game logic through systems. Custom processors must be inherited from a Processor class.

Group

Processors execute game logic through iterating groups. Groups are entities that are filtered by specific components. The same entity may lay in many groups.

sealed class ProcessorMove : Processor, ITick
	{
          // Define a group. The group is defined via Processor parent class
          Group<ComponentMove,ComponentPosition> groupMovables;

	        // ITick interface Adds Tick method. It's an update with delta time.
	  	public void Tick(float delta)
		{
		        // iteration through group
			foreach (ent entity in groupMovables)
			{
				var cMove     = entity.ComponentMove();
				var cPosition = entity.ComponentPosition();
				// do some logic
			}
		}

        }

If you are going to use only one group in the processor you can take a slightly different approach. There is no difference except that you will type less.

// Define a group from the processor. The group defined in this way called source.
sealed class ProcessorMove : Processor<ComponentMove,ComponentPosition>, ITick
	{

	        // ITick interface Adds Tick method. It's an update with delta time.
	  	public void Tick(float delta)
		{
		        // iteration through group
			foreach (ent entity in source)
			{
				var cMove     = entity.ComponentMove();
				var cPosition = entity.ComponentPosition();

				// do some logic
			}
		}

        }

Group events

You can make events for entities that were added or removed from the group. It's "similar" to Unity OnEnable and OnDisable logic.

sealed class ProcessorMove : Processor, ITick
	{
          // Define a group. The group is defined via Processor parent class
          Group<ComponentMove,ComponentPosition> groupMovables;

	     // To work with events use method HandleEvents
	        public override void HandleEvents()
		{
		         // work with all entities that were removed to the group on the current frame
	                foreach (ent entity in groupMovables.removed)
			{

			}

                        // work with all entities that were added to the group on the current frame
			foreach (ent entity in groupMovables.added)
			{

			}
                }


	        // ITick interface Adds Tick method. It's an update with delta time.
	  	public void Tick(float delta)
		{
		        // iteration through group
			foreach (ent entity in groupMovables)
			{
				var cMove     = entity.ComponentMove();
				var cPosition = entity.ComponentPosition();

				// do some logic
			}
		}
        }

Starters

The Starter class is the entry point of a game scene. You define all your Processors and Scene dependecies there. How you define your processors matters for execution order.

        // Inherit from Starter class
	sealed class StarterGame : Starter
	{
                // override Setup method. It's like Awake in Unity.
		protected override void Setup()
		{
			Add<ProcessorMotion>();
			Add<ProcessorInput>();
			Add<ProcessorPlayer>();
                  }
         }

Actors

The Actor is a monobehavior class that allows communicating between unity game objects and framework. Most of the time you will inherit from Actors when defining new objects.

The Actor class is for defining what is your Entity. You use Actors only to add some components to the Entity, to have a connection between Framework and Unity out of the box and for initial setup of the object. You can use it as view class if you like MVC patterns.

How to create an Actor

public class ActorModuleReactor : Actor
    {
       // use the FoldoutGroup attribute to decorate components nicely
       // in groups in the Unity Inspector
       [FoldoutGroup("Setup")]
        public ComponentStateMachine componentStateMachine;

        [FoldoutGroup("Setup")]
        public ComponentRecycle componentRecycle;

        // Use setup method to define Actor.
        protected override void Setup()
        {
             // add your components to the Entity of the Actor
             entity.Set(componentStateMachine);
             entity.Set(componentRecycle);

             // add a component by its type.
             entity.Set<ComponentDescription>;
        }
    }
