node-potrace

A NodeJS-compatible fork of Potrace in JavaScript with some additions, which is in turn a port of the original Potrace — a tool for tracing bitmaps.

Example and demo

Original image	Potrace output	Posterized output

(Example image inherited from online demo of the browser version)

Usage

Install

npm install potrace

Basic usage

var potrace = require('potrace'),
    fs = require('fs');

potrace.trace('./path/to/image.png', function(err, svg) {
  if (err) throw err;
  fs.writeFileSync('./output.svg', svg);
});

You can also provide a configuration object as a second argument.

var params = {
  background: '#49ffd2',
  color: 'blue',
  threshold: 120
};

potrace.trace('./path/to/image.png', params, function(err, svg) {
  /*...*/
});

If you want to run Potrace algorithm multiple times on the same image with different threshold setting and merge results together in a single file - posterize method does exactly that.

potrace.posterize('./path/to/image.png', { threshold: 180, steps: 4 }, function(err, svg) {
  /*...*/
});

// or if you know exactly where you want to break it on different levels

potrace.posterize('./path/to/image.png', { steps: [40, 85, 135, 180] }, function(err, svg) {
  /*...*/
});

Advanced usage and configuration

Both trace and posterize methods return instances of Potrace and Posterizer classes respectively to a callback function as third argument.

You can also instantiate these classes directly:

var potrace = require('potrace');

// Tracing

var trace = new potrace.Potrace();

// You can also pass configuration object to the constructor
trace.setParameters({
  threshold: 128,
  color: '#880000'
});

trace.loadImage('path/to/image.png', function(err) {
  if (err) throw err;

  trace.getSVG(); // returns SVG document contents
  trace.getPathTag(); // will return just <path> tag
  trace.getSymbol('traced-image'); // will return <symbol> tag with given ID
});

// Posterization

var posterizer = new potrace.Posterize();

posterizer.loadImage('path/to/image.png', function(err) {
  if (err) throw err;

  posterizer.setParameter({
    color: '#ccc',
    background: '#222',
    steps: 3,
    threshold: 200,
    fillStrategy: potrace.Posterize.FILL_MEAN
  });

  posterizer.getSVG();
  // or
  posterizer.getSymbol('posterized-image');
});

Callback function provided to loadImage methods will be executed in context of the Potrace/Posterizer instance, so if it doesn't go against your code style - you can just do

new potrace.Potrace()
  .loadImage('path/to/image.bmp', function() {
    if (err) throw err;
    this.getSymbol('foo');
  });

Jimp module is used on the back end, so first argument accepted by loadImage method could be anything Jimp can read: a Buffer, local path or a url string. Supported formats are: PNG, JPEG or BMP. It also could be a Jimp instance (provided bitmap is not modified)

Parameters

Potrace class expects following parameters:

turnPolicy - how to resolve ambiguities in path decomposition. Possible values are exported as constants: TURNPOLICY_BLACK, TURNPOLICY_WHITE, TURNPOLICY_LEFT, TURNPOLICY_RIGHT, TURNPOLICY_MINORITY, TURNPOLICY_MAJORITY. Refer to this document for more information (page 4)
(default: TURNPOLICY_MINORITY)
turdSize - suppress speckles of up to this size
(default: 2)
alphaMax - corner threshold parameter
(default: 1)
optCurve - curve optimization
(default: true)
optTolerance - curve optimization tolerance
(default: 0.2)
threshold - threshold below which color is considered black. Should be a number in range 0..255 or THRESHOLD_AUTO in which case threshold will be selected automatically using Algorithm For Multilevel Thresholding
(default: THRESHOLD_AUTO)
blackOnWhite - specifies colors by which side from threshold should be turned into vector shape
(default: true)
color - Fill color. Will be ignored when exporting as <symbol>. (default: COLOR_AUTO, which means black or white, depending on blackOnWhite property)
background - Background color. Will be ignored when exporting as <symbol>. By default is not present (COLOR_TRANSPARENT)

Posterizer class has same methods as Potrace, in exception of .getPathTag(). Configuration object is extended with following properties:

fillStrategy - determines how fill color for each layer should be selected. Possible values are exported as constants:
- FILL_DOMINANT - most frequent color in range (used by default),
- FILL_MEAN - arithmetic mean (average),
- FILL_MEDIAN - median color,
- FILL_SPREAD - ignores color information of the image and just spreads colors equally in range 0..<threshold> (or <threshold>..255 if blackOnWhite is set to false),
rangeDistribution - how color stops for each layer should be selected. Ignored if steps is an array. Possible values are:
- RANGES_AUTO - Performs automatic thresholding (using Algorithm For Multilevel Thresholding). Preferable method for already posterized sources, but takes long time to calculate 5 or more thresholds (exponential time complexity)
  (used by default)
- RANGES_EQUAL - Ignores color information of the image and breaks available color space into equal chunks
steps - Specifies desired number of layers in resulting image. If a number provided - thresholds for each layer will be automatically calculated according to rangeDistribution parameter. If an array provided it expected to be an array with precomputed thresholds for each layer (in range 0..255)
(default: STEPS_AUTO which will result in 3 or 4, depending on threshold value)
threshold - Breaks image into foreground and background (and only foreground being broken into desired number of layers). Basically when provided it becomes a threshold for last (least opaque) layer and then steps - 1 intermediate thresholds calculated. If steps is an array of thresholds and every value from the array is lower (or larger if blackOnWhite parameter set to false) than threshold - threshold will be added to the array, otherwise just ignored.
(default: Potrace.THRESHOLD_AUTO)
all other parameters that Potrace class accepts

Notes:

When number of steps is greater than 10 - an extra layer could be added to ensure presence of darkest/brightest colors if needed to ensure presence of probably-important-at-this-point details like shadows or line art.
With big number of layers produced image will be looking brighter overall than original due to math error at the rendering phase because of how layers are composited.
With default configuration steps, threshold and rangeDistribution settings all set to auto, resulting in a 4 thresholds/color stops being calculated with Multilevel Thresholding algorithm mentioned above. Calculation of 4 thresholds takes 3-5 seconds on average laptop. You may want to explicitly limit number of steps to 3 to moderately improve processing speed.
